Description
Advantages of the drying oven wicket
The above rollers and buckles allow the metal sheet (or aluminum plate) to dry and run in a separate state from the wicket, avoiding dot shaped scratches and burns caused by the original wicket.
1. Strong rigidity: The synchronization and stability of rigidity (flatness) and servo feeding and discharging effectively prevent scratches between the product and the wicket during transportation;
2. Anti-scalding: The wicket and the sheet metal store (release) heat synchronously, greatly reducing the temperature difference between the product and the wicket to avoid product scalding to the maximum extent possible.
3. Low weight: The reduction in the weight of the wicket also reduces the operating energy consumption of the drying oven, which is an energy-saving process transformation measure.
4. Longer service life
Drying Oven Wicket Application
Can-making/Metal sheet Painting and Printing Ovens
Drying Oven Wicket Description
1. The steelness and flatness of the wicket are the key components of more
than 100 pieces / minute. LONGLI wicket has been confirmed in practical use in
this field.
2. The yield resistance strength of the furnace rack is 470 Mpa
3. Electroplating adopts three nickel and one chromium process, coating
thickness 16um and potential difference 120MA
4. LONGLI Patent ￠10 × 2 hollow core tube wicket, with strong rigidity, high flatness, and light weight.
5. Two on the left and two on the right of the upper ear are angled to achieve the suspension of the coated product on the wicket, reducing the chance of scratches and scalds.
6.Total weight of 36M drying room wicket: 1.68kg/piece × 3650 pieces=6132kg
7.20 → 200 ℃ Drying conditions consume heat energy: 15m3/h (natural gas)
8. The integrated forming process adopted ensures CNC bending accuracy.
9. Using automated laser welding, the product should be controlled to meet the requirements of industrial and mining use
Wicket Photo Show
